Jielong
FMWORLD
| Quantity: | |
|---|---|
| Model | 4LZ-4.0D ( for Philippines) | 4LZ-4.0D | |
| Type | Self-propelled Whole-feeding | Self-propelled Whole-feeding | |
| Dimension (Operation) | Length(mm) | 4360 | 4660 |
| Width(mm) | 2890 | 2465 | |
| Height(mm) | 2830 | 3000 | |
| Weight(kg) | 2750 | 2300 | |
| Engine | Type | Inline, Watercool, Four-stroke, Direct Injection | Inline, Watercool, Four-stroke, Direct Injection |
| Power(HP) | 70 | 70 | |
| RPM(r/min) | 2600 | 2650 | |
| Fuel tank(L) | 130 | 72 | |
| Other equipment | fulltime drive system | ||
| Gear Box Model | Hydraulic Type with HST | Hydraulic Type with HST | |
| Chassis | Track(mm) | 500 x 90 x 51 mm | 400*90*46mm |
| Track Center(mm) | 1150 | 1030 | |
| Ground Clearance(mm) | 320 | 320 | |
| Harvesting | Cutting Width(mm) | 2000 | 2000 |
| Feeding Capacity (kg/s) | 4.0 | 3.0 | |
| Cutting Bar Lift | Hydraulic Control | Hydraulic Control | |
| Threshing | Type | Axial Flow Type with Beat Bars | Axial Flow Type with Beat Bars |
| Threshing Cylinder (mm) | 620x2010 | 550*1295 | |
| Filtrate Type | Vibrating Sieves+ Centrifugal Fan | Vibrating Sieves+ Centrifugal Fan | |
| Discharging | Side Grain Tank(0.3m^3) | Manual Type | Manual Type |
| Work efficiency(ha./h) | 0.37-0.66ha | 0.25-0.47 | |
| Crops | Rice, Wheat, Rapessed | Rice, Wheat, Rapessed | |
