Parameter | UOM | Specification |
Connection Method | / | Traction-type |
Width of the Pickup | mm | 2260 |
Number of Spring Teeth / Spacing | mm | 85 / 128 |
Protection Device | / | Overrunning clutch and slipping clutch |
Pick-up Device Lifting | / | Hydraulic cylinder control |
Tedder Tine / Protection Device | / | 6 tedder tines / Slipping clutch |
Feeding Fork / Protection Device | / | Fork-type feeding fork |
Number of Cutters (Optional) | pcs | 0–13–26 |
Number of Knotters / Binding Capacity | / | 6 double-knot devices / 30 bundles |
Plunger Frequency | strokes/min | 47 |
Plunger Movement Stroke | mm | 740 |
Bale Cross-section | mm | 1200 × 875 |
Bale Length | mm | Adjustable to 2743 |
Tire Model | / | 620/40R-22.5 |
Transmission Box | / | Closed two-stage deceleration, overrunning clutch |
Weight (Empty Baling Chamber) | kg | 10630 |
