model | 9G-28 lawn mower | 9G-21 lawn mower | 9G-24 lawn mower |
Drive mode | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min |
Suspension type | Rear | Rear | Rear |
Installation type | Three point opening and closing | Three point opening and closing | Three point opening and closing |
Minimum traction force (KW) | ≥35KW(≥35hp) | ≥29KW(≥40hp) | ≥35KW(≥48hp) |
Working range(mm) | 2800 | 2100 | 2400 |
Working speed (km/h) | 4-10 | 4-8 | 4-8 |
Working dimensions (mm) | 1300*4380*1300 | 1300*4000*1300 | 1300*4000*1300 |
Transportation dimensions (mm) | 1300*1600*3100 | 1300*1600*1250 | 1300*1600*2800 |
Machine weight (KG) | 490 | 450 | 460 |
Cutting height (mm) | ≤80 | ≤80 | ≤80 |
Number of cutterheads (only) | 7 | 5 | 6 |
Number of blades (only) | 7*2 | 5*2 | 6*2 |
Hydraulic folding | yes | yes | yes |
center height adjustment | Adjustable | Adjustable | Adjustable |
