Item | Unit | Value |
Model name | / | 1ZLZD-5.6 |
Connection type | / | Towed |
Machine weight | kg | 4500 |
Number of harrows | pcs | 65 |
Harrow diameter | mm | 460 |
Harrow spacing | mm | 175 |
Working width | mm | 5600 |
Minimum angle of harrow group | / | 0 |
Maximum angle of harrow group | / | 12 |
Working state dimensions(length) | mm | 7400 |
Working state dimensions(width) | mm | 6000 |
Working state dimensions(height) | mm | 1500 |
Tire specification | / | 20.5-70-16 |
Number of tires | pcs | 4 |
Wheel track | mm | 865-1455-865 |
Walking cylinder specification | / | YG100-63-270 |
Number of walking cylinders | / | 2 |
Folding cylinder specification | / | YG80-50-670 |
Number of folding cylinders | / | 4 |
Matching power | kw | 125-162 |
