model | 9L285 rake | 9L315 rake | 9L365 rake | 9L655ASL rake | 9L460 rake |
Drive mode | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min |
Suspension type | Rear | Rear | Rear | Rear | Rear |
Installation type | Three point opening and closing | Three point opening and closing | Three point opening and closing | Three point opening and closing | Three point opening and closing |
Minimum traction force (KW) | ≥20KW(≥27.2hp) | ≥20KW(≥27.2hp) | ≥20KW(≥27.2hp) | ≥44KW(≥60hp) | ≥29.4KW(≥40hp) |
Working range(mm) | 2800 | 3100 | 3600 | 6550 | 4600 |
Working speed (km/h) | 5-20 | 5-20 | 5-20 | 6-12 | 5-20 |
Working dimensions (mm) | 3100*3100*1600 | 3300*3200*1700 | 3300*3700*1800 | 5100*6500*1250 | 3800*4300*1800 |
Transportation dimensions (mm) | 3100*1600*1600 | 3300*1600*1700 | 3300*1650*1800 | 3600*2900*3600(After folding) | 3800*2650*1800(After folding) |
Machine weight (KG) | 325 | 345 | 405 | 1220 | 525 |
Turning diameter (mm) | 2800 | 2800 | 2920 | 2900 | 3500 |
Number of turntables (only) | 1 | 1 | 1 | 2 | 1 |
Quantity of gear racks per turntable (only) | 8(Removable) | 9(Removable) | 10(Removable) | 10(Removable) | 12(Removable) |
Tire specifications | 16*6.50-8 | 16*6.50-8 | 16*6.50-8 | 10/80-12AW 6PR | 18*8.50-8 4PR |
center height adjustment | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable |
Grass curtain | Curtain | Curtain | Curtain | Curtain | Curtain |
