| 型号 | Model | 排种机2BMQW-6 | Seed machine 2BMQW-6 | 种/肥箱容积（L） | Seed/fertilizer tank volume (L) | 种箱36L×6/肥箱500L×2 | Seed box 36L×6/fertilizer box 500L×2 | |||
| 结构型式 | Structural type | 气力式/牵引式 | Pneumatic/traction type | 种/肥排量调节方式 | Seed/fertilizer discharge adjustment method | 种：齿轮传动调节 肥：旋钮把手调节外槽轮开口大小 | Seed: gear drive adjustment Fertilizer: knob handle to adjust the size of the outer groove wheel opening | |||
| 配套动力范围（kW） | Matching power range (kW) | 66.2~103 | 66.2~103 | |||||||
| 外形尺寸（长×宽×高）（mm） | Dimensions (length × width × height) (mm) | 3365×4005×1895 | 3365×4005×1895 | 传动机构型式 | Transmission mechanism type | 地轮、链传动 | Ground wheel, chain drive | |||
| 作业速度范围（km/h） | Operating speed range (km/h) | 6~10 | 6~10 | 开沟器型式 | Opener type | 种：双圆盘；肥：单圆盘 | Seed: double disc; fertilizer: single disc | |||
| 作业小时生产率（km²/h） | Operating hourly productivity (km²/h) | 1.68~2.94 | 1.68~2.94 | 开沟器数量（个） | Number of openers (pieces) | 播种6个；施肥6个 | 6 for sowing; 6 for fertilizing | |||
| 行距（mm） | Row spacing (mm) | 550~650 | 550~650 | 开沟器深度调节范围（mm） | Opener depth adjustment range (mm) | 播种10~70；施肥50~150 | 10~70 for sowing; 50~150 for fertilizing | |||
| 工作行数（行） | Number of working rows (rows) | 6 | 6 | 地轮型式 | Ground wheel type | 凹条纹充气轮胎 | Concave stripe pneumatic tire | |||
| 工作幅宽（mm） | Working width (mm) | 3300~3900 | 3300~3900 | 地轮直径（mm） | Ground wheel diameter (mm) | Ø767 | Ø767 | |||
| 排种器型式 | Type of seeding device | 气力式（金属材料） | Pneumatic type (metal material) | 地轮高度调节范围（mm） | Ground wheel height adjustment range (mm) | 无调节 | No adjustment | |||
| 排种器数量（个） | Number of seeding devices (pieces) | 6 | 6 | 破茬清垄工作部件型式 | Stubble breaking and ridge clearing working parts type | 双侧星型拨草轮+波纹盘 | Dual-sided star-shaped weeding wheel + corrugated disc | |||
| 排种器驱动方式 | Drive mode of seeding device | 地轮传动 | Ground wheel drive | 风机型式 | Blower type | 机械离心风机 | Mechanical centrifugal fan | |||
| 排肥器型式 | Type of fertilizer device | 外槽轮式 | External groove wheel type | 风机叶轮直径（mm） | Blower impeller diameter (mm) | Ø400 | Ø400 | |||
| 排肥器数量（个） | Number of fertilizer devices (pieces) | 12 | 12 | 覆土器型式 | Soil cover type | V型橡胶轮 | V-shaped rubber wheel | |||
| 排肥器驱动方式 | Drive mode of fertilizer device | 地轮传动 | Ground wheel drive | 镇压器型式 | Package type | |||||
